Multitube Unarmoured

Multitube Unarmoured

Multitube Unarmoured Cable is an indoor/outdoor cable. To stop water from getting inside, it has several loose tubes packed with fibres and thixotropic jelly. Better tensile strength and antibuckling characteristics are offered by fibre reinforced plastic, which also has a cable flooding compound placed in the core’s interstices to stop water intrusion. available in LSZH and UVHDPE sheaths.

Category:

Description

Physical Characteristics
Fiber Count 24F 48F 72F 96F 144F
No. of Tubes 4 4 6 8 12
Fibers / Tube 6F 12F 12F 12F 12F
FRP Dimension (mm) 2.0 ± 0.1 2.0 ± 0.1 2.0 ± 0.1 3.5 ± 0.1 2.0 ± 0.1
Outer sheath thickness (± 0.3) 1.8 1.8 1.8 1.8 1.8
Cable Diameter (mm) 10.0 ± 0.5 10.0 ± 0.5 10.0 ± 0.5 11.2 ± 0.5 13.5 ± 0.5
Cable Weight (Kg/km) 75± 10% 75± 10% 75± 10% 90± 10% 125± 10%
Mechanical and Environmental Characteristics
Test Standard/Notes Product Accomplishment
Max. Tensile Strength (N) IEC-60794-1-E1 2000
Bending Radius IEC-60794-1-E11 Dynamic = 20D, Static = 10D
Crush Resistance (N/100 ) IEC-60794-1-E3 2000
Impact Strength (N.m) IEC-60794-1-E4 20
Torsion IEC-60794-1-E7 ± 180°
Drip Test IEC-60794-1-E14 30 cm, 70ºC, 24 hr
Water Penetration IEC-60794-1-F5B 1m water head, 3m samples, 24 hrs
IEC 60793-1 & 60794-1
Telecordia GR-20 Core
ANSI/TIA 568-C.3 & ISO/IEC 11801

Printing

ORIENT CABLES <Fibre Type> <Fibre Count> <Type of Cable> <MONTH> <YEAR> <Cable ID> <XXXX> METER

Wooden Drums or Export Quality Drum
Length: 1 / 2 / 3 km +- 10% or Custom Lengths
Blue Orange Green Brown Grey White Red Black Yellow Violet Pink Aqua/Nat.
